Product Details
＋
Based on Trilogy®, the #1 electronic standalone access locks, Networx™ Locking Products are networked to save staff labor, eliminating door-todoor programming and audit trail retrieval, by communicating wirelessly via Ethernet or 802.11B/G, all while providing the ultra dependability, functionality & long battery life, original Trilogys are known for.
Features:
- Global lockdown and passage from keypad or PC, schedules, 35K event log, door position status indicator, request-to-exit, door ajar/kick-in, remote release options
- Ideal for use with strikes, mags, electrified exit devices
- 5000 users with 3-6 digit PINs or HID® ID cards
- Versatile for indoors or outside, ideal for education, healthcare, government, airports, courts & retail
- Familiar Trilogy operation; flexible system monitoring, control & programming
- NETPDK with built in HID prox reader accepts most HID Proximity cards and keyfobs
SPECIFICATIONS
| Lock Type: | Keypad |
| User Codes: | 5000 |
| Code Length: | 3-6 digits |
| Programming: | Keypad / PC |
| Vandal-Proof Keypad: | All metal 12-button |
| Audit Trail Events: | 35000 |
| Scheduled Events: | 500 |
| Reader/Credential Support: |
NETPDK for HID Prox |
| Lockdown (Privacy): | Global lockdown via lock, server or optional keyfob |
| Relay Options: | Yes |
| Battery/Cycles Typical: | 4 C cells; 500,000 or up to 5 years |
| Architectural Finishes: | US26D - Satin Chrome |
Downloads:
